ARRIS VT5804 48CH 0mw/25mw/100mw/200mw/400mw/600mw Switchable Video Transmitter
ARRIS VT5804 48CH 0mw/25mw/100mw/200mw/400mw/600mw Switchable Video TransmitterARRIS VT5804 48CH 0mw/25mw/100mw/200mw/400mw/600mw Switchable Video TransmitterARRIS VT5804 48CH 0mw/25mw/100mw/200mw/400mw/600mw Switchable Video Transmitter

ARRIS VT5804 48CH 0mw/25mw/100mw/200mw/400mw/600mw Switchable Video Transmitter

Item# MA0102
USD $24.99
  • DESCRIPTION
  • REVIEWS
QTY:

Main Features:
Stable output power, long transmission range (0.5KM+@25mW; 1KM@200mW; 2KM+@600mW with stock antenna)
0mw/25mw/100mw/200mw/400mw/600mw switchable
Output power and frequency setting can be done in OSD interface through remote controller
Fast frequency lock
Ultra light weight--Only 6g

Specifications:
Input Voltage: 7V-24V
Power: 0mw/25mw/100mw/200mw/400mw/600mw (switchable)
Power Consumption: +12V/260mA@600mW
Output Imdependance: 50Ohm
Output Power: 27.5 to 28.5dbm
Channel: 48CH 8CH in E raceband
Video Format: NTSC/PAL
Antenna Connector: MMCX Connector
Dimension: 36mm x 36mm x 5mm
Weight: 6g (Without antenna)

Output Power and Frequency Setting
1. Long press the button 10 Seconds, then short press would change the power 25mW/100mW/200mW/400mW/600mW.
2. Short Press one time, it will change the Channel ( CH1-CH8)
3. Long press 2 Senconds and then short press , will change the FR ( A-F)
4. The freuqncy and power can be adjusted in OSD interface through radio

Note: Please make sure the antenna has installed well before powering.

ARRIS VT5804 Frequency Table

      FR

CH

CH1

CH2
CH3
CH4
CH5
CH6
CH7
CH8

A

5865
5845
5825
5805
5785
5765
5745
5725
B
5733
5752
5771
5790
5809
5828
5847
5866
C
5705
5685
5665
5645
5885
5905
5925
5945
D
5740
5760
5760
5800
5820
5840
5860
5880
E
5658
5695
5695
5769
5806
5843
5880
5917
F
5362
5399
5399
5473
5510
5547
5584
5621

Package Included:
ARRIS VT5804 video TX x 1
Antenna x 1
Wire x 1
